Tyre Pressure Monitoring System (Some Models)
When DrivingTyre Pressure Monitoring SystemTyre Pressure Monitoring System (Some Models)

Tyre Pressure Monitoring System (Some Models)

The Tyre Pressure Monitoring System (TPMS) monitors the air pressure of all four tyres. If the air pressure of one or more tyres is too low, the system warns the driver by indicating the tyre pressure monitoring system warning light in the instrument cluster and operating a beep sound. The system monitors the tyre pressures indirectly using the data sent from the ABS wheel speed sensors.

To allow the system to operate correctly, the system needs to be initialized with the specified tyre pressure (value on the tyre pressure label). Follow the procedure and perform the initialization.

Refer to Tyre Pressure Monitoring System Initialization (Search).

The warning light flashes when the system has a malfunction.

Refer to Warning Lights (Search).





  • Each tyre, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tyre inflation pressure label. (If your vehicle has tyres of a different size than the size indicated on the vehicle placard or tyre inflation pressure label, you should determine the proper tyre inflation pressure for those tyres.)

    As an added safety feature, your vehicle has been equipped with a tyre pressure monitoring system (TPMS) that illuminates a low tyre pressure telltale when one or more of your tyres is significantly under-inflated. Accordingly, when the low tyre pressure telltale illuminates, you should stop and check your tyres as soon as possible, and inflate them to the proper pressure. Driving on a significantly under-inflated tyre causes the tyre to overheat and can lead to tyre failure. Under-inflation also reduces fuel efficiency and tyre tread life, and may affect the vehicle's handling and stopping ability.

    Please note that the TPMS is not a substitute for proper tyre maintenance, and it is the driver's responsibility to maintain correct tyre pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tyre pressure telltale.

    Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.

    The TPMS malfunction indicator is combined with the low tyre pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the system may not be able to detect or signal low tyre pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tyres or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tyres or wheels on your vehicle to ensure that the replacement or alternate tyres and wheels allow the TPMS to continue to function properly.

  • To avoid false readings, the system samples for a little while before indicating a problem. As a result it will not instantaneously register a rapid tyre deflation or blow out.

Close Caution
View Caution



Because this system detects slight changes in tyre conditions, the timing of the warning may be faster or slower in the following cases:

  • The size, manufacturer, or the type of tyres is different from the specification.

  • The size, manufacturer, or the type of a tyre is different from the others, or the level of tyre wear is excessively different between them.

  • A run-flat tyre, studless tyre, snow tyre, or tyre chains are used.

  • An emergency tyre is used (The tyre pressure monitoring system warning light may flash and then continue illuminating).

  • A tyre is repaired using the emergency flat tyre repair kit.

  • The tyre pressure is excessively higher than the specified pressure, or the tyre pressure is suddenly lowered for some reason such as a tyre burst during driving.

  • The vehicle speed is lower than about 15 km/h (9.3 mph) (including when the vehicle is stopped), or the drive period is shorter than 5 minutes.

  • The vehicle is driven on an extremely rough road or a slippery, icy road.

  • Hard steering and rapid acceleration/deceleration are repeated such as during aggressive driving on a winding road.

  • Load on the vehicle is applied to a tyre such as by loading heavy luggage to one side of the vehicle.

  • System initialization has not been implemented with the specified tyre pressure.
