Manual Transaxle Shift Pattern

The shift pattern of the transaxle is conventional, as shown.



Depress the clutch pedal all the way down while shifting; then release it slowly.



Your vehicle is equipped with a device to prevent shifting to R (reverse) by mistake. Push the shift lever downward and shift to R.





Do not use sudden engine braking on slippery road surfaces or at high speeds:

Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous. The sudden change in tyre speed could cause the tyres to skid. This could lead to loss of vehicle control and an accident.

Always leave the shift lever in 1 or R position and set the parking brake when leaving the vehicle unattended:

Otherwise the vehicle could move and cause an accident.

Close Warning
View Warning



  • Keep your foot off the clutch pedal except when shifting gears. Also, do not use the clutch to hold the vehicle on an upgrade. Riding the clutch will cause needless clutch wear and damage.

  • Do not apply any excessive lateral force to the shift lever when changing from 5th to 4th gear. This could lead to the accidental selection of 2nd gear, which could result in damage to the transaxle.

  • Make sure the vehicle comes to a complete stop before shifting to R. Shifting to R while the vehicle is still moving may damage the transaxle.

Close Caution
View Caution



  • If shifting to R is difficult, shift back into neutral, release the clutch pedal, and try again.

  • If the engine has stopped due to stalling, it can be restarted by depressing the clutch pedal within 3 seconds of the engine stopping.

    The engine cannot be restarted even if the clutch pedal is depressed under the following conditions:

    • The driver's door is open.

    • The driver's seat belt is unfastened.

    • The clutch pedal is not released completely after the engine stalled.

    • The clutch pedal is depressed with the engine not stopped completely.

  • (With parking sensor system)

    When the shift lever is shifted to the R position with the ignition switched ON, the parking sensor system is activated and a beep sound is heard.

    Refer to Parking Sensor System (Search).
