Fuel-Filler Flap and Cap
When removing the fuel-filler cap, loosen the cap slightly and wait for any hissing to stop, then remove it:
Fuel spray is dangerous. Fuel can burn skin and eyes and cause illness if ingested. Fuel spray is released when there is pressure in the fuel tank and the fuel-filler cap is removed too quickly.
Before refuelling, stop the engine, and always keep sparks and flames away from the filler neck:
Fuel vapour is dangerous. It could be ignited by sparks or flames causing serious burns and injuries.
Additionally, use of the incorrect fuel-filler cap or not using a fuel-filler cap may result in a fuel leak, which could result in serious burns or death in an accident.
Do not continue refuelling after the fuel pump nozzle shuts off automatically:
Continuing to add fuel after the fuel pump nozzle has shut off automatically is dangerous because overfilling the fuel tank may cause fuel overflow or leakage. Fuel overflow and leakage could damage the vehicle and if the fuel ignites it could cause a fire and explosion resulting in serious injury or death.
Always use only a designated Mazda fuel-filler cap or an approved equivalent, available at an expert repairer, we recommend an Authorised Mazda Repairer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Fuel-Filler Flap
When the fuel-filler flap end is pressed with the doors unlocked, the fuel-filler flap rises.
The fuel-filler flap operates in conjunction with the door locking/unlocking mechanism.
Make sure to lock both the doors when leaving the vehicle.
Refer to Door Locks (Search).
To close, press the fuel-filler flap until a click sound is heard.
Lock the doors after closing the fuel flap.
If the fuel flap is closed after locking the doors, the fuel flap cannot be locked.
Fuel-Filler Cap
To remove the fuel-filler cap, turn it anticlockwise.
Attach the removed cap to the inner side of the fuel flap.
To close the fuel-filler cap, turn it clockwise until a click is heard.
